EXPERT PLASMA 100 HF Professional Plasma Cutting Machine

EXPERT PLASMA 100 HF is a professional plasma cutting device designed for distortion-free cutting of carbon steel, stainless steel, aluminium, brass and copper. The unit provides electronically controlled smooth cutting current adjustment, allowing precise parameter configuration according to material type and thickness.

A clear digital display enables accurate parameter setting, ensuring stable operation and high cutting quality. Contactless plasma arc ignition reduces electrode and nozzle wear, extends consumable life and improves cut quality. The possibility of using a torch carriage ensures even greater cutting precision and consistency.

With the P80 handheld plasma torch, the machine is capable of performing separation cuts on carbon steel up to 50 millimetres thick and quality cuts up to 45 millimetres.

The fan cooling system ensures efficient heat dissipation and increases performance. Built-in overload protection enhances reliability and operational safety.

Technical Specifications

Input voltage: three phase 400 volts, 50 hertz
Network protection: C25 amperes
Power: 13.6 kilowatts
No-load voltage: 300 volts
Maximum cutting current: 100 amperes
Current at 60 percent duty cycle: 100 amperes
Protection class: IP21S
Weight: 37 kilograms
Compressed air pressure: 5 to 6 bar
Maximum cutting thickness: separation cut up to 50 millimetres, quality cut up to 45 millimetres
Compressed air consumption: 250 litres per minute
Cutting current adjustment range: 30 to 100 amperes

Package Includes

EXPERT PLASMA 100 HF unit
P80 handheld plasma torch with six metre cable and central connector
Three metre ground cable
