Welding machine E.065H H2O inverter for MIG/MAG, MMA

code E.065H

Welding Synergy inverter for MIG/MAG, MMA and Gouging (incl. MMA 99 jobs, cable bundle 2m, arc M6W 5m UD!)

• Full synergy or manual mode;
• Instant access to five currents;
• Possibility to save up to 99 jobs;
• Excellent welding characteristics in mixed gas and CO²;
• Continuous voltage regulations;
• Electronic regulations of the choke;
• Settable PreGas, PostGas, Burn Back;
• MMA Initial speed module;
• Electrode welding up to diameter 5mm and gouging (500A);
• Ecological cooling mode;
• Front wheel with a brake;
• Welds with wire up to diameter 0.6 – 0.8 mm, or 1.0 – 1.2 mm of different metals and alloys (such as carbon steel and alloy steel, aluminum, etc.) ;
• Higher wire feeder class - four-rollers feed with large rollers and incremental encoder results in safe and reliable wire feeding

TECHNICAL DATA

Mains Voltage: 3x 400 V
Mains frequency: 50 Hz
Max. no load voltage: 92 V
Main fuse: 32 A
Welding current range [MIG-MAG/MMA]..............: 40 - 500A / 10 - 400A
Max. effective current [MIG-MAG/MMA]................: 31.3 A / 30.3 A
Welding current [MIG-MAG/MMA] (DC=100%): 420 A / 400 A
Welding current [MIG-MAG/MMA] (DC=60%)...: 500 A / ----
Welding current [MIG-MAG/MMA] (DC=x%)......: 500@60% / 400@100%
Voltage setting: continuous
Protection degree: IP23S
Standards: EN 60974-1
Dimensions: 474 x 846 x 956 mm
Weight: 84 kg
------------------------------------
Wire speed m/min: 1.0 - 26.0
Spool diameter .......: 300 mm
Spool weight .............: 18 kg
------------------------------------
Cooling power (Q=1l/min): 0.74 kW
Total liquid content ...............: 3.5l
Max. pressure ............................: 3.5 bar
Max. flow .....................................: 8.0 l/min

* Before ordering, check availability.
