Welding machine ALFAIN aXe 250 SMART GAS inverter for MIG/MAG

Welding machine aXe 250 SMART GAS inverter for MIG/MAG and MMA*

code E.098-4P

Welding synergy inverter for MIG/MAG and MMA* with a preparation for PULSE* mode MIG/MAG (option for upgrade)

• Full synergy or manual mode;
• Instant access to six currents;
• Excellent welding characteristics in mixed gas and CO²;
• Welds with wire up to diameter 0.6 – 0.8 mm, or 1.0 – 1.2 mm of different metals and alloys (such as carbon steel and alloy steel, aluminum, etc.);
• Continuous voltage regulations;
• Settable Pregas, Postgas, Burn back;
• Initial speed Module MMA;
• MAG welding with self-shielding wire (reverse polarity);
• *On request module MMA (welding with electrodes up to diameter of 4.0mm);
• 4 roll feeders;
• Electronic regulations of the choke;
• Ecological cooling mode;
• Led ligth in the feeder space;
• Front wheel with a brake;
• Higher wire feeder class - four-rollers feed with large rollers and incremental encoder results in safe and reliable wire feeding

TECHNICAL DATA

Mains Voltage: 3x 400 V
Mains frequency: 50 / 60 Hz
Max. no load voltage: 63.1 V
Main fuse: 16 A
Welding current range [MIG-MAG/MMA]..............: 20 - 250A / 30 - 250A
Max. effective current [MIG-MAG/MMA]................: 12.9 A / 13.0 A
Welding current [MIG-MAG/MMA] (DC=100%): 210 A / 190 A
Welding current [MIG-MAG/MMA] (DC=60%)...: 250 A / 230 A
Welding current [MIG-MAG/MMA] (DC=x%)......: 250@60% / 250@50%
Voltage setting: continuous
Insulation class: F
Protection degree: IP23S
Standards: EN 60974-1, EN 60974-10 cl.A
Dimensions: 474 x 911 x 670 mm
Weight: 47.0 kg
------------------------------------
Wire speed m/min: 0.5 - 20.0
Spool diameter .......: 300 mm
Spool weight .............: 18 kg

* Before ordering, check availability.

---
