SPOT-25T Stationary Spot Welding Machine

The SPOT-25T is a stationary spot welding machine designed for double-sided welding of low-carbon steel, stainless steel and galvanized sheets up to 3.5 + 3.5 mm thick. It is especially recommended for repair work, small-scale production and automotive body workshops. The machine features 4 power levels (low / medium / high / highest) and a built-in timer that allows precise welding time adjustment from 0.00 to 9.99 s, ensuring repeatability and consistent weld quality.
⚠️ Note: A cooler is required for proper operation and must be purchased separately.

Features

• Double-sided welding up to 3.5 + 3.5 mm sheets

• 4 welding levels: low, medium, high, highest

• Welding time adjustment: 0.00–9.99 s

• Built-in timer for repeatable welds

• Overload protection

• Stationary design with 500 mm arm reach

• External cooler required (not included)

Application
The SPOT-25T is ideal for automotive body repair shops, metal workshops and production facilities requiring powerful and precise sheet welding. It is commonly used for assembling and repairing heavy-duty sheet structures.

Technical parameters

• Rated supply voltage: 400V; 50Hz (2 phases)

• Network protection: C63

• Rated power: 25 kVA

• No-load secondary voltage: 2.25–3.58V

• Welding current adjustment: 4-step

• Welding time adjustment: 0.00–9.99 s

• Max. sheet thickness: 3.5 + 3.5 mm

• Arm reach: 500 mm

• Duty cycle: 20%

• Degree of protection: IP21

• Weight: 100 kg

• Scope of delivery: machine and arms with electrodes

• Power cord and plug not included
